Onesight^®AR·Construction Assistant

Positioning the BIM model at the centimeter level and overlaying it 1:1 on the construction site, AR visualization guides on-site construction verification, progress management, and quality management, ensuring that users can control every step of the construction process, discover errors, reduce rework, improve collaboration, achieve efficient and high-quality construction, and assist projects in obtaining BIM model assets that are consistent with the actual model.

Get the solution

Bringing BIM 1:1 to the site, Landing the [Last Kilometre] of BIM to construction

Traditionally

BIM cannot be presented on-site. High rate of constrcution errors, and low construction and acceptance efficiency.

Onesight®AR Construction Assistant

Bring the BIM model to the site for 1:1 comparison, facilitating design disclosure, reducing construction errors, controlling project progress, improving acceptance efficiency, and saving capital costs.

Construction preparation ｜ Construction program simulation

Through AR technology, the BIM model is positioned to the site in multiple angles and locations to assist in visualizing the effect of the completed project. Combined with the project schedule, simulate the construction process of the entire building project, and view the progress of the project in real time as the project construction advances.

How it works

Foundation construction ｜ Pre-embedded pipeline backfill before verification

Before construction, the pipeline/pit BIM overlay is used to quickly locate and place lines on the site through AR technology to assist in pre-buried laying and pit excavation; before backfilling and after pit excavation, the pipeline laying is completed, the visualization technology is used to verify the pipeline and avoid errors and omissions in reworking.

How it works

Main construction ｜ reserved holes and steel structure verification

Using visualization technology, collaborate with civil engineering and mechanical and electrical specialties to complete the disclosure and verification of the reserved hole size, position, and quantity.

How it works

Mechanical and Electrical Installation | Mechanical and Electrical Pipeline Verification

Through BIM+AR technology, provide guidance on installation methods and result comparison verification for prefabricated machine rooms before and after construction, timely identify mechanical and electrical installation problems, and promptly attach rectification orders.

How it works

Fine Decoration Engineering ｜ Net Height Control and Decoration Engineering Verification

In the key area of net height control, use AR+MESH function to perform net height verification and inspection on the installed mechanical and electrical pipelines; Support comparative verification of fine decoration projects.

How it works

Completion and delivery ｜ Inspection of concealed works

View hidden projects on the mobile end, providing insight into the location and direction of underground pipelines, hidden equipment pipelines, and the comprehensive properties of each BIM component.

How it works
